| Basic specification |
| Engine model |
6BT5.9 |
| Rated power/speed |
100/2200kw/rpm |
| Dimension(LxWxH) |
8015×2380×3050mm |
| Operating weight(Standard) |
11000kg |
| Performance specification |
| Travelling speed ,forward |
5?8?13?20?30?42km/h |
| Travelling speed ,reverse |
5?13?30km/h |
| Tractive force(f=0.75) |
61.3KN |
| Max. gradeability |
20% |
| Tire inflation pressure |
300kPa |
| Working hydraulic pressure |
16MPa |
| Transmission pressure |
1.3~1.8MPa |
| Operating specification |
| Max. steering angle of front wheels |
±49° |
| Max. lean angle of front wheels |
±17° |
| Max. oscillation angle of front axle |
±15° |
| Max. oscillation angle of balance box |
16 |
| Frame articulation angle |
±27° |
| Min. turning radius using articulation |
6.6m |
| Biade |
| Maximum lift above ground |
410mm |
| Maximum depth of cutting |
535mm |
| Maximum blade position angle |
90° |
| Blade cutting angle |
28°—70° |
| Circle reversing rotation |
360° |
| Moldboard width X height |
3710×610mm |
