XCMG Official XC6-3507K Telescopic Handlers for sale
XC6-3507 Telescopic handler
1、XC6 is the latest XCMG' agricultural version telehandlerwhich features the highest operation simplicity, safety and efficiency.
2、The panoramic cab and the XCMG’svisual identity appearance design feature good fashion and elegance.
3、The integrated static-pressure stepless variable drivesystem realizes full speed range drive and stable driving.
4、The four-wheel drive and multiple steering modes(including four-wheel, two-wheel, and crab steering modes) realize super-strongoff-road capability and adapt to diversified working conditions.
5、The inching control technology and special overloadcontrol system are applied to achieve high operation safety and reliability.
6、The electro-hydraulic proportional control for theworking system features accurate, stable, and efficient operations.
7、The advanced human-machine interactivity, intelligentheat dissipation system, and dedusting control system embody high technologicsense and intelligence.
Description | Unit | Parameter value | |
Engine Power | kW | 70 | |
|
|
Overall weight (±5%) | kg | 7850 | |
Overall dimensions (±2％) | mm | 5065×2250×2470 | |
Maximum traveling speed | m/h | 30 | |
Turning radius | mm | 3880 | |
Maximum effective load | kg | 3500 | |
Effective load at maximum extending length | kg | 1250 | |
Maximum lifting height (±100) | mm | 7150 | |
Maximum forward reach (±100) | mm | 3600 | |
Center distance of load | mm | 600 | |
Luffing angle (±1º) | ° | -3~65 | |
Inclination of fork carrier (forward (±1.5)/backward (±1)) | ° | 90/17.5 | |
Maximum traction force | KN | 70 | |
Wheelbase (±2%) | mm | 2985 | |
Wheeltread (±2%) | mm | 1840 | |
