HGP32 Concrete Placing Boom
1、The automatic climbing system of SCHWING placing boom hasbeen tested by the market. The adoption of this climbing technology is good forour company to form products and enter into the market rapidly.
2、The accumulation of relevant experience has laid afoundation for developing an automatic climbing system of better performanceand stronger operability.
3、External linkage is also one of the typical marks inintegrating SCHWING technology. The design of "FrontTwo, Rear Three” structural type external linkage haseffectively improved the problem of boom transverse swing.
4、The optimization of connecting pin roll fixing ways hasensured the distance between booms, avoided possibly existing interferenceproblem and guaranteed reliability.
5、All loop tanks are equipped with full filtering system ofoil suction and oil return which ensures system cleanness, prolongs servicelife of hydraulic elements and hydraulic oil, and generates higher operationalreliability of hydraulic system.
6、Boom, standard section assembly, base structure andturret, etc. adopt high strength structural steel, with higher reliability.

Description	Unit		Parameter value
Max. placing radius	m		32
Slewing angle of the placing boom	°		370
Temperature of work environment	℃		-20~+50
Independent height	m		21
Column type			4m +6m
Mounting type			Floor
Climbing speed	m/mim		0.5~0.8
Climbing type			Top-climbed oil tank
Motor model			YX3-180L-4 V1
Power	Kw		22
Rev.	rpm		1470
System pressure	MPa		33
Flow	L/min		34
Oil tank capacity	L		120
Control mode			Panel control/wired control/remote control
Cleaning methods of delivery pipe			Washing/dry cleaning
Gross mass (including counterweight)	mm		21
Boom type	mm		4R
Delivery pipeline diameter	mm		DIN125
Length of end hose	m		3
1st section	Length	mm	9155
	Rotation angle	°	90
2nd section	Length	mm	7815
	Rotation angle	°	180
3rd section	Length	mm	7755
	Rotation angle	°	180
4th section	Length	mm	7025
	Rotation angle	°	240
