| 发电机组技术规格书generating set specification |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC50(D40S3K) |
|
| 额定功率(kw) | 40 | 备用功率(kw) | 44 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 72 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 880 | 外形尺寸(mm) | 1805*893*1170 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-40S3 | 接口类型 | SAE3/11.5 |
| Control system model | Connect type |
| 冷却液容量(L) | ≈22.5 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC63(D50S3K) |
|
| 额定功率(kw) | 50 | 备用功率(kw) | 55 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 90 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 940 | 外形尺寸(mm) | 1900*893*1170 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-50S3 | 接口类型 | SAE3/11.5 |
| Control system model | Connect type |
| 冷却液容量(L) | ≈22.5 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC80(D64S3K) |
|
| 额定功率(kw) | 64 | 备用功率(kw) | 70 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 115 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 970 | 外形尺寸(mm) | 1950*893*1170 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-64S3 | 接口类型 | SAE3/11.5 |
| Control system model | Connect type |
| 冷却液容量(L) | ≈22.5 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC100(D80S3K) |
|
| 额定功率(kw) | 80 | 备用功率(kw) | 88 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 144 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 1020 | 外形尺寸(mm) | 1983*973*1185 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-80S3 | 接口类型 | SAE 3#/11.5# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈23.8 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC125(D100S3K) |
|
| 额定功率(kw) | 100 | 备用功率(kw) | 110 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 180 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 1080 | 外形尺寸(mm) | 1983*973*1185 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-100S3 | 接口类型 | SAE 3#/11.5# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈23.8 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC150(D120S3K) |
|
| 额定功率(kw) | 120 | 备用功率(kw) | 132 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 217 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 1250 | 外形尺寸(mm) | 2400*940*1376 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-120S3 | 接口类型 | SAE 3#/11.5# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈36 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC188(D150S3K) |
|
| 额定功率(kw) | 150 | 备用功率(kw) | 165 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 271 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 1330 | 外形尺寸(mm) | 2413*940*1376 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-150S3 | 接口类型 | SAE 3#/11.5# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈36 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC200(D160SK) |
|
| 额定功率(kw) | 160 | 备用功率(kw) | 176 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 289 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤±1 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 1520 | 外形尺寸(mm) | 2515*980*1500 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-160SC | 接口类型 | SAE 2#/11.5# |
| Control system model | Connect type |
| 冷却液容量(L) | 40 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC225(D180SK) |
|
| 额定功率(kw) | 180 | 备用功率(kw) | 198 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 325 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 1540 | 外形尺寸(mm) | 2505*980*1500 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-180SC | 接口类型 | SAE 2#/11.5# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈40 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC250(D200SK) |
|
| 额定功率(kw) | 200 | 备用功率(kw) | 220 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 361 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 1750 | 外形尺寸(mm) | 2706*1040*1486 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-200SC | 接口类型 | SAE 2#/11.5# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈43 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC313(D250S4K) |
|
| 额定功率(kw) | 250 | 备用功率(kw) | 275 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 451 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 2850 | 外形尺寸(mm) | 3147*1230*1670 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-250S1 | 接口类型 | SAE 1#/14# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈75.5 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC350(D300SKE) |
|
| 额定功率(kw) | | 备用功率(kw) | 300 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 492 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 2900 | 外形尺寸(mm) | 3155*1105*1626 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-300SC | 接口类型 | SAE 1#/14# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈68.2 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC375(D300S1K) |
|
| 额定功率(kw) | 300 | 备用功率(kw) | 330 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 541 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 2970 | 外形尺寸(mm) | 3147*1230*1670 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-300S1 | 接口类型 | SAE 1#/14# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈75.5 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC450(D400S4KE) |
|
| 额定功率(kw) | | 备用功率(kw) | 400 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 656 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 4300 | 外形尺寸(mm) | 3533*1400*1992 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-400S | 接口类型 | SAE 0.5#/14# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈129 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-C500(D400S4K) |
|
| 额定功率(kw) | 400 | 备用功率(kw) | 440 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 722 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 4300 | 外形尺寸(mm) | 3548*1400*1992 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-400S | 接口类型 | SAE 0#/18# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈129 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC563(D500S2KE) |
|
| 额定功率(kw) | | 备用功率(kw) | 500 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 820 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 4450 | 外形尺寸(mm) | 3548*1400*1992 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-500S | 接口类型 | SAE 0#/18# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈129 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-C625(D500S2K) |
|
| 额定功率(kw) | 500 | 备用功率(kw) | 550 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 902 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 4450 | 外形尺寸(mm) | 3548*1400*1992 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-500S | 接口类型 | SAE 0#/18# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈129 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC688(750)(D600S2KE) |
|
| 额定功率(kw) | | 备用功率(kw) | 600 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 984 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 4700 | 外形尺寸(mm) | 3624*1400*1992 |
| weight | Overall dimension |
| 控制系统型号 | EW571P-600S | 接口类型 | SAE 0#/18# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈129 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC800(D700SKE) |
|
| 额定功率(kw) | | 备用功率(kw) | 700 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 1148 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 7940 | 外形尺寸(mm) | 4433*1775*2378 |
| weight | Overall dimension |
| 控制系统型号 | EW561P-700W | 接口类型 | SAE 0#/18# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈214 | |
| Coolant capacity |
机组型号(订货号)
Gen-set Model(Order Number) | SD-SC900(D800SKE) |
|
| 额定功率(kw) | | 备用功率(kw) | 800 |
| Rated output | Standby output |
| 额定频率(Hz) | 50 | 额定电流(A) | 1312 |
| Rated frequency | Rated current |
| 瞬态频率偏差(％) | ≤+12,≤-10 | 瞬态电压偏差(％) | ≤+25, ≤-20 |
| Transient frequency deviation | Transient voltage deviation |
| 频率恢复时间(s) | ≤5 | 电压恢复时间(s) | ≤6 |
| Frequency recovery time | Voltage recovery time |
| 频率降 (％) | ≤5 | 稳态电压偏差(％) | ≤±2.5 |
| Frequency droop | Steady-state voltage deviation |
| 稳态频率带(％) | ≤1.5 | 电压调制(％) | 0.3 |
| Steady-state frequency band | Voltage modulation |
| 功率因数 | 0.8 | 启动电压(v) | 24 V |
| Rated capacity factor | Starting voltage |
| 重量(kg) | 8000 | 外形尺寸(mm) | 4433*1775*2378 |
| weight | Overall dimension |
| 控制系统型号 | EW561P-800W | 接口类型 | SAE 0#/18# |
| Control system model | Connect type |
| 冷却液容量(L) | ≈214 | |
| Coolant capacity |
