Items
|
Unit
|
2WD
|
4WD
|
|
Total length
|
mm
|
9750
|
9750
|
|
Total
|
mm
|
2490
|
2490
|
|
Total
|
mm
|
2820
|
2820
|
|
Axle base
|
mm
|
2500
|
2500
|
|
Rated work
|
m
|
22.4
|
22.4
|
|
Max. platform
|
m
|
20.7
|
20.7
|
|
Max.work range
|
m
|
19.3
|
19.3
|
|
Arm luffing range
|
°
|
-15~+76
|
-15~+76
|
|
Arm luffing time
|
s
|
60
|
60
|
|
Arm contraction time
|
s
|
70
|
70
|
|
Max.rotation speed
|
r/min
|
0.5
|
0.5
|
|
Max.tail swing
|
mm
|
1190
|
1190
|
|
Platform size
|
mm
|
1800×900×1150
|
1800×900×1150
|
|
Platform rotation range
|
°
|
180°
|
180°
|
|
Turntable rotation radius
|
mm
|
2470
|
2470
|
|
Total weight under travel condition
|
kg
|
13380
|
13380
|
|
Rated load
|
kg
|
230
|
230
|
|
Max. load
|
kg
|
480
|
480
|
|
Max.travel speed
|
km/h
|
6
|
5.6
|
|
Min. turning radius
|
m
|
5.5
|
5.5
|
|
Min.ground clearance
|
mm
|
270
|
270
|
|
Max. gradeability
|
%
|
30
|
45
|
|
Engine model
|
|
B3.3 (Tier3)
|
B3.3 (Tier3)
|
|
Rated engine power
|
kW/(r/min)
|
45/(2200)
|
45/(2200)
|
|
Solid tyre
|
|
9.00-20/7.0
|
9.00-20/7.0
|
