Technical Specifications
|
Model
|
SQ6.3SK2Q
|
Unit
|
|
Max Lifting Capacity
|
6300
|
kg
|
|
Max Lifting Moment
|
15.7
|
T.M
|
|
Recommend Power
|
20
|
kw
|
|
Max Oil Flow of Hydraulic System
|
40
|
L/min
|
|
Max Pressure of Hydraulic System
|
20
|
MPa
|
|
Oil Tank Capacity
|
90
|
L
|
|
Rotation Angle
|
All Rotation
|
|
|
Crane Weight
|
2117/2270
|
kg
|
|
Installation Space
|
900
|
mm
|
|
Choice of Chassis
|
CA1163P7K2L3E ; CA1176PK2L9T3A95 ; CA1170PK2L7T3EA80; CA1140PK2L3EA80; DFL1140B; EQ1126KJ1; HFC1202KR1K3; EQ1141NBJ2; EQ5161GFJ7; BJ1317VNPJJ-S5; EQ5201GFJ6; LZ1160LCMT; DFL1250A9; BJ5317ZNPJJ-S; NXG1160D3ZAL1X
|
SQ6.3SK2Q Lifting capability diagram
|
Working radius (m)
|
2.5
|
3.82
|
6.17
|
8.5
|
|
Lifting capacity (kg)
|
6300
|
2900
|
1600
|
1200
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
