Technical Specifications

Dimensions	Unit
Overall length	Mm	13790
Overall	Mm	2800
Overall	Mm	3675
Weight
Dead weight in travel state	Kg	42490
Front axle load	Kg	16490
Rear axle load	Kg	26000
Power
Engine model		WD615.334
Engine rated output	Kw(r/min)	247/2200
Engine rated torque	N.m(r/min)	1350/1400
Travel
Max.travel speed	Km/h	80
Min. turning diameter	M	24
Min. ground clearance	Mm	327
Approach angle	?	21
Departure angle	?	15
Max. gradeability	%	40
Fuel consumption of per 100km	L	≈42
Lifting performance
Max. total rated lifting load	T	50
Min. rated working radius	M	3
Turning radius at swing table tail	Mm	3500
Base boom max. load moment	Kn.m	1838
Base boom	M	11.4
Full-extend boom	M	43.3
Full-extend boom+Jib	m	59.3
Outrigger longitudinal distance span	M	5.91
Outrigger lateral distance span	M	6.9
Working speed
Boom elevating time	S	88
Boom telescoping time	S	180
Max. slewing speed	r/min	2
Main winch max. speed(single line)	m/min	130
Auxiliary winch max.speed(single line)	m/min	130

&Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
