Technical Specifications
|
Model
|
SQ3.2ZK1
|
Unit
|
|
Max Lifting Moment
|
6.72
|
t.m
|
|
Max Lifting Capacity
|
3200
|
kg
|
|
Recommend Power Needed At Recommend Oil Flow
|
14
|
kw
|
|
Max Oil Flow of Hydraulic System
|
25
|
L/min
|
|
Rated Pressure Of Hydraulic System
|
22
|
MPa
|
|
Oil Tank Capacity
|
60
|
L
|
|
Rotation Angle
|
370
|
?
|
|
Crane Weight
|
1100
|
kg
|
|
Installation Space
|
850
|
mm
|
|
Choice of Chassis
|
EQ1092FJ1;EQ1092FJ;NKR77PLLWCJAY ;DFL1120B D530;EQ1081GJ12D5;HFC1083K103R1D;EQ1092F3GJ1;EQ5121GFJ;
|
|
SQ3.2ZK1 Lifting capability diagram
|
|
Working radius (m)
|
2.1
|
4.15
|
5.8
|
|
Lifting capacity (kg)
|
3200
|
1400
|
1000
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
