GR100 Motor Grader

Technical Specifications

Basic specification
Engine model 4BT3.9
Rated power/speed 75/2400kw/rpm
Dimension(LxWxH) 6880×2375×3150mm
Operating weight(Standard) 7000kg
Performance specification
Travelling speed ,forward 5,10,20,39km/h
Travelling speed ,reverse 8,25km/h
Tractive force(f=0.75) 41.6KN
Max. gradeability 20%
Tire inflation pressure 350KPa
Working hydraulic pressure 16MPa
Transmission pressure 1.3~1.8MPa
Operating specification
Max. steering angle of front wheels ±50°
Max. lean angle of front wheels 17°
Max. oscillation angle of front axle ±15°
Max. oscillation angle of balance box
Frame articulation angle ±27°
Min. turning radius using articulation 5.9m
Biade
Maximum lift above ground 300mm
Maximum depth of cutting 350mm
Maximum blade position angle 45°
Blade cutting angle 28°—70°
Circle reversing rotation 120°
Moldboard X 3048×500mm
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
