Technical Specifications
|
Classificatory
|
Item
|
Unit
|
Parameter
|
|
Outline dimension
|
Overall length
|
mm
|
14950
|
|
Overall
|
mm
|
3000
|
|
Overall
|
mm
|
3950
|
|
Axle base
|
Axle 1, Axle 2
|
mm
|
1420
|
|
Axle 2, Axle 3
|
mm
|
2420
|
|
Axle 3, Axle 4
|
mm
|
1875
|
|
Axle 4, Axle 5
|
mm
|
1350
|
|
Axle 5, Axle 6
|
mm
|
1400
|
|
Wheel base
|
mm
|
2610/2307
|
|
Mass
|
Total mass in travel state
|
kg
|
62000
|
|
Axle load
|
Axle 1, Axle 2
|
kg
|
8800/8800
|
|
Axle 3, Axle 4
|
kg
|
9200/12700
|
|
Axle 5, Axle 6
|
kg
|
12700/9800
|
|
Power
|
Crane superstructure engine
|
Rated power
|
kw/(r/min)
|
162/2100
|
|
Rated torque
|
N.m/(r/min)
|
854/1400
|
|
Rated speed
|
r/min
|
2100
|
|
Crane carrier engine
|
Rated power
|
kw/(r/min)
|
390/1800
|
|
Rated torque
|
N.m/(r/min)
|
2400/1080
|
|
Rated speed
|
r/min
|
2000
|
|
Travel performance
|
Travel speed
|
Max. travel speed
|
km/h
|
70
|
|
Min. stable travel speed
|
km/h
|
2.1
|
|
Min. turning diameter
|
m
|
24
|
|
Min. ground clearance
|
mm
|
275
|
|
Approach angle
|
(°)
|
23
|
|
Departure angle
|
(°)
|
14
|
|
Braking distance (at 30km/h)
|
m
|
≤ 10
|
|
Max. grade-ability
|
%
|
40
|
|
Fuel consumption for 100km
|
L
|
80
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
