Feeding technology: reliable and endurable

Large range of the clearance adjusting of the separate rod (330-480mm) meets the requirements of different paving conditions and reduces the segregation along the height direction.
It adopts Φ420X360 large diameter and coarse pitch blade, reducing the rpm and segregation.
Two reverse blades in material separate box reduce the medium segregation area.

Technical Specifications

Item	Unit	RP902
Basic Paving	m	3
Max Paving	m	9
Max Paving Thickness	mm	350
Paving Speed	m/min	0~18
Travel Speed	km/h	0~2.2
Theoretical Productivity	t/h	700
Capacity	t	14
Hopper Capacity	%	20
Gradeability	mm/3m	≤2
Pavement Evenness	%	±0.02
Transverse Leveling Accuracy	%	-1~3
Centre Crown Ratio
Engine Model		BF6M1013E
Engine Power	kw	137
Engine Speed	r/min	2300
Diesel Tank Capacity	L	270
Machine Weight	t	23.8~28.6
Tamper Vibration Frequency	Hz	0~50
Screed Heating		Electric Heating
Auger and Conveyor Control		Automatic Control by Ultrasonic Sensors
Automatic Leveling Control		Digital

& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
