Technical Specifications
|
Main technical specifications
|
unit
|
XMR15S
|
|
Operating weight
|
kg
|
1600
|
|
Distributed weight in vibration drum(front/rear)
|
kg
|
800/800
|
|
Static linear load(front/rear)
|
N/cm
|
88/88
|
|
Speed
|
km/h
|
0-9
|
|
Gradeability
|
%
|
30
|
|
min turning radius (out)
|
mm
|
2700
|
|
min ground clearance
|
mm
|
250
|
|
wheel base
|
mm
|
1350
|
|
steering angle
|
|
34°
|
|
swing angle
|
|
7°
|
|
vibration frequency
|
Hz
|
70
|
|
nominal amplitude
|
mm
|
0.4
|
|
centrifugal force
|
KN
|
17
|
|
drum diameter
|
mm
|
582
|
|
compacting
|
mm
|
893
|
|
Engine model
|
|
perkins 403D-11
|
|
Rated speed
|
r/min
|
2600
|
|
Rated power
|
kw
|
17.3
|
|
Overall dimensions
|
mm
|
2118*977*2279
|
|
Rated oil wear
|
g/kw.h
|
235
|
|
Fuel tank capacity
|
L
|
15
|
|
Hydraulic tank capacity
|
L
|
24
|
|
Sprinkler capacity
|
L
|
110
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
